Parameter Code
Version
PLANAR 44D–24
PLANAR 44D12
Nominal Supply Voltage, V
24
12
Fuel Type
Diesel Oil
Heating Efficiency:
max, kW,
min, kW,
4
1
Heated Air Volume:
Max , m3 /h
Min, m3 /h
120
70
Fuel Consumption at:
Max power, l/h
Min power, l/h
0.51
0.12
Start/Stop Mode
Manual
Maximum Weight, kg
8
Heater power consumption, W
Doesn’t exceed while heating mode
Max, W
Min, W
58
10
62
